STATUS – MISTING (MENU 4.4)
1. Misting system status – Displays if the Misting system is ON or OFF
2. Actual start trigger – Displays the current start trigger if any
3. Actual stop trigger – Displays the current stop trigger if any
4. Pump status – Displays the current condition of the pump (Rest/On/Off)
5. Max valves allowed – Maximum number of valves allowed to operate
simultaneously defined in menu 8.2.4 Misting Configuration
6. Limitation – Displays a restriction on the Misting system due to a higher priority
event
7. Valve # – Misting Valve number as defined in the System Installation – Digital
Inputs menu (8.1.1)
8. Calculated spray – Displays the calculated spray processes duration
9. Calculated pause – Displays the calculated pause between sprays
10. Calculated cycle – Displays the calculated cycle duration
11. Pause – Displays the run time of the current Pause
12. V. status – Displays the current status of each individual valve
4.4 Misting Stat
Zone 1
19/01/09 16:21
1. Misting system status
2. Actual start trigger
3. Actual stop trigger
4. Pump status
5. Max valves allowed
6. Limitations
Off
VPD
None
Rest
5
None
Misting Valve
7. Valve #
8. Calc spray
9. Calc pause
10. Calc cycl
11. Pause
12. V. Status
1
0:00:05
0:06:00
0:06:05
Spray
2
0:00:05
0:06:00
0:06:05
Spray
3
0:00:05
0:06:00
0:06:05
Wait
