SETUP – SYSTEM CALIBRATION – SCREEN (MENU 7.10.2)
NMC Pro supports two calibration methods:
• Manual Calibration
• Automatic Calibration
Manual Calibration
To maintain accurate screen performance, calibrate the system at regular intervals. There
are two different calibration methods, depending on the way the screen movement is
measured:
•
Time (default screen control)
•
Measured (used when a Screen Position sensor is installed)
Table 2: Screen System Calibration Course of Action
TIME MEASURED
1. Make sure all manual switches of the
electrical switch board are set to the
AUTO position
1. Make sure all manual switches of the
electrical switch board are set to the
AUTO position
2. Set the Drive screen %  0% 2. Set the Drive screen %  0%
3. Verify visually that the screen is
completely closed
3. Verify visually that the screen is
completely closed
4. Change Calibrate now

YES 4. Change Calibrate now

YES
5. Wait until the Calibrate now changes
back to NO
5. Wait until the Calibrate now changes
back to NO
6. Set the Drive screen %  100% 6. Set the Drive screen %  100%
7. Verify visually that the screen is completely
opened
7. Verify visually that the screen is
completely open
8. Change Calibrate now

YES 8. Change Calibrate now

YES
7.10.2 Screens
Zone 1
19/01/09 16:21
1. Screen # 1 2
2. Drive screen %
3. Calib pos %
4. Calibrate now
5. Auto Calib
6. Auto Calib hh:mm
None
0
No
Off
00:00
0
0
Yes
Off
00:00
Measurements
7. Calculated pos %
8. Measured pos %
9. Control type
10. Measured mV
11. Curve mV-%
12 Li i i
40
40
Meas.
0
N
70
67
Time
3000
N
