NETGEAR GS748T User Manual

223
GS748T Smart Switch
The following table describes the information displayed in the IP Binding Table.
Field Description
Interface Displays the interface to which the IP ACL is bound.
Direction Specifies the packet filtering direction for ACL. The only valid direction is
Inb
ound, which means the IP ACL rules are applied to traffic entering the
port.
ACL Type Displays the type of ACL assigned to selected interface and direction.
ACL ID Displays the ACL Number identifying the ACL assigned to selected interface
a
nd direction.
Seq No. Displays the Sequence Number signifying the order of specified ACL relative
to other ACLs assign
ed to selected interface and direction.
To delete an IP ACL-to-interface binding, select the check box next to the interface and click
Delete.

NETGEAR GS748T Specifications

General

Basic switching RJ-45 Ethernet ports quantity	48
MAC address table	16000 entries
Packet buffer memory	1.632 MB
Maximum data transfer rate	1 Gbit/s
Latency	20 µs
I/O ports	48 RJ-45 connectors for 10BASE-T, 100BASE-TX, and 1000BASE-T (Auto Uplink on all ports) 4 SFP slots for fiber Gigabit Ethernet modules
Dimensions (WxDxH)	440 x 260 x 43 mm
Power requirements	100-240VAC 50/60 Hz
Networking features	10BASE-T, 100BASE-TX, 1000BASE-T
Connectivity technology	Wired
Full duplex	Yes
Networking standards	IEEE 802.3x
Minimum system requirements	Category 5 network cables Network card for each PC Network software (e.g., Windows)
Mean time between failures (MTBF)	69930 h
Safety	UL listed (UL 1950)/cUL, IEC950/EN60950
LED indicators	Link, Power
Power consumption (typical)	70 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	4000 g
