NETGEAR GS748T User Manual

37
GS748T Smart Switch
Click Clear to delete all entries from the table. The table is repopulated as the IPv6 neighbors
are discovered on the network. Click Refresh to refresh the screen with most recent data.
The following table describes the information the IPv6 Network Interface Neighbor Table
di
splays
Field Description
IPv6 Address Specifies the IPv6 address of neighbor or interface.
MAC Address Specifies MAC address associated with an interface.
IsRtr Indicates whether the neighbor is a router. If the neighbor is a router, the value is
T
rue. If the neighbor is not a router, the value is False.

NETGEAR GS748T Specifications

General

Basic switching RJ-45 Ethernet ports quantity	48
MAC address table	16000 entries
Packet buffer memory	1.632 MB
Maximum data transfer rate	1 Gbit/s
Latency	20 µs
I/O ports	48 RJ-45 connectors for 10BASE-T, 100BASE-TX, and 1000BASE-T (Auto Uplink on all ports) 4 SFP slots for fiber Gigabit Ethernet modules
Dimensions (WxDxH)	440 x 260 x 43 mm
Power requirements	100-240VAC 50/60 Hz
Networking features	10BASE-T, 100BASE-TX, 1000BASE-T
Connectivity technology	Wired
Full duplex	Yes
Networking standards	IEEE 802.3x
Minimum system requirements	Category 5 network cables Network card for each PC Network software (e.g., Windows)
Mean time between failures (MTBF)	69930 h
Safety	UL listed (UL 1950)/cUL, IEC950/EN60950
LED indicators	Link, Power
Power consumption (typical)	70 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	4000 g
