Chapter 10. ACLs | 145
ProSafe 7000 Managed Switch Release 8.0.3
3. Permit all the other traffic.
(Netgear Switch) (Config-mac-access-list)#permit any
(Netgear Switch) (Config-mac-access-list)#exit
4. Apply the MAC ACL acl_bpdu to port 1/0/2.
(Netgear Switch) (Config)#interface 1/0/2
(Netgear Switch) (Interface 1/0/2)#mac access-group acl_bpdu in
Web Interface: Set up a MAC ACL with Two Rules
1. Create MAC ACL 101 on the switch.
a. Select Security > ACL > MAC ACL. A screen similar to the following displays.
b. In the Name field, enter acl_bpdu.
c. Click Add to create ACL acl_bpdu.
2. Create a new rule associated with the ACL acl_bpdu.
a. Select Security > ACL > MAC ACL > MAC Rules. A screen similar to the following
displays.
a. In the ACL Name field, select acl_bpdu.
b. In the Action field, select Deny.
