NETGEAR WAC505 User Manual

The default user name is admin. The password is the one that you specified the first time that you
logged in.The user name and password are case-sensitive.
The Dashboard page displays.
4. Select Management > Configuration > Wireless > Basic.
The page that displays lets you select an SSID.
5. Click the trash can icon to the right of the SSID.
The WiFi network is removed.
Enable or Disable Client Separation for a WiFi Network
By default, client separation is disabled for a WiFi network (SSID or VAP), allowing communication between
WiFi clients that are associated with different WiFi networks on the access point. For additional security,
you can enable client separation.
To enable or disable client separation for a WiFi network:
1. Open a web browser from a computer that is connected to the same network as the access point or to
the access point directly through an Ethernet cable or WiFi connection.
2. Enter the IP address that is assigned to the access point.
A login window opens.
3. Enter the access point user name and password.
The default user name is admin. The password is the one that you specified the first time that you
logged in.The user name and password are case-sensitive.
The Dashboard page displays.
4. Select Management > Configuration > Wireless > Basic.
The page that displays lets you select an SSID.
5. Click the > button to the left the SSID.
The settings for the selected SSID display.
6. Under Client Separation, select one of the following radio buttons:
• Enable. Client separation is enabled for the WiFi network.
• Disable. Client separation is disabled for the WiFi network.
7. Click the Apply button.
Your settings are saved.
Hide or Broadcast the SSID for a WiFi Network
By default, a WiFi network (SSID or VAP) broadcasts its network name (also referred to as the SSID) so
that WiFi clients can detect the SSID in their scanned network lists. For additional security, you can turn off
the SSID broadcast and hide the SSID so that users must know the SSID to be able to join the WiFi network.
Manage the Basic WiFi and Radio Features
36
Insight Managed Smart Cloud Wireless Access Point WAC505 User Manual

NETGEAR WAC505 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Output current	2.5 A
Output voltage	12 V
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Internal	No
Placement	Ceiling, Wall
Product color	White
Security algorithms	802.1x RADIUS, EAP, EAP-TLS, PEAP, TTLS, WPA, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) features	SSID broadcast on/off
Antenna gain level (max)	4 dBi

Weight and Dimensions

Depth	165 mm
Width	175 mm
Height	35 mm
Weight	256 g
