- Serial Number. The serial number of the access point.
- Current Time.The current system time of the access point.
- Uptime. The time since the access point was last restarted.
Wireless Settings section.The following settings are displayed, with separate columns for the 2.4
GHz and 5 GHz radios:
- Wireless Mode. The operating WiFi mode of the radio.
- Channel / Frequency. The channel and frequency that are used by the radio.
- Number of Clients. The number of clients that are connected to the radio.
IPv4 Settings section.The following settings are displayed:
- IPv4 Address. The IPv4 address of the access point.
- Subnet Mask. The subnet mask of the access point.
- Default Gateway.The default gateway for the access point.
- DHCP Client. The status of DHCP client (Enabled or Disabled).
View the WiFi Radio Settings
To view the WiFi radio settings of the access point:
1. Open a web browser from a computer that is connected to the same network as the access point or to
the access point directly through an Ethernet cable or WiFi connection.
2. Enter the IP address that is assigned to the access point.
A login window opens.
3. Enter the access point user name and password.
The default user name is admin. The password is the one that you specified the first time that you
logged in.The user name and password are case-sensitive.
Monitor the Access Point and the Network
113
Insight Managed Smart Cloud Wireless Access Point WAC505 User Manual

Table of Contents

Other manuals for NETGEAR WAC505

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR WAC505 and is the answer not in the manual?

NETGEAR WAC505 Specifications

General IconGeneral
2.4 GHzYes
Networking standardsIEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates10, 100, 1000 Mbit/s
Maximum data transfer rate1167 Mbit/s
Maximum data transfer rate (5 GHz)867 Mbit/s
Maximum data transfer rate (2.4 GHz)300 Mbit/s
Output current2.5 A
Output voltage12 V
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports1
InternalNo
PlacementCeiling, Wall
Product colorWhite
Security algorithms802.1x RADIUS, EAP, EAP-TLS, PEAP, TTLS, WPA, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) featuresSSID broadcast on/off
Antenna gain level (max)4 dBi
Weight and Dimensions IconWeight and Dimensions
Depth165 mm
Width175 mm
Height35 mm
Weight256 g
