NETGEAR WAC505 User Manual

• To move a device from the Available Stations table to the Trusted Stations table, select the check
box for the device and click the << Move button.
• To remove a device from the Trusted Stations table, select the check box for the device and click
the Remove button.
When you remove the device from the Trusted Stations table, the device is not moved to the Available
Stations table.
9. Click the Apply button.
Your settings are saved. WiFi devices in the Trusted Stations table can access the WiFi network to
which you apply the ACL (see Select a MAC ACL for a WiFi Network on page 40).
Import an Existing MAC Access Control List
You can import an existing access control list (ACL) that is based on up to 64 MAC addresses.You can
import the list into the first MAC ACL (referred to as Group 1 and named Corporate), into the second MAC
ACL (referred to as Group 2 and named Guest), or into both.
The file with MAC addresses must be in the following format:
• Entries in the file must be MAC addresses only in hexadecimal format with each octet separated by a
hyphen, for example 00-11-22-33-44-55.
• You must separate entries with a comma.
• The file must be in text format (that is, with a .txt or .cfg extension).
You can use a MAC ACL to control which WiFi devices can access a WiFi network.You can apply a MAC
ACL to more than one WiFi network.
To import an existing MAC ACL:
1. Open a web browser from a computer that is connected to the same network as the access point or to
the access point directly through an Ethernet cable or WiFi connection.
2. Enter the IP address that is assigned to the access point.
A login window opens.
3. Enter the access point user name and password.
The default user name is admin. The password is the one that you specified the first time that you
logged in.The user name and password are case-sensitive.
The Dashboard page displays.
Manage Access and Security
71
Insight Managed Smart Cloud Wireless Access Point WAC505 User Manual

NETGEAR WAC505 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Output current	2.5 A
Output voltage	12 V
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Internal	No
Placement	Ceiling, Wall
Product color	White
Security algorithms	802.1x RADIUS, EAP, EAP-TLS, PEAP, TTLS, WPA, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) features	SSID broadcast on/off
Antenna gain level (max)	4 dBi

Weight and Dimensions

Depth	165 mm
Width	175 mm
Height	35 mm
Weight	256 g
