• Turn a radio on. Select the Turn Radio ON check box for the radio.
• Turn a radio off. Clear the Turn Radio ON check box for the radio.
6. Click the Apply button.
Your settings are saved.
Change the WiFi Mode for a Radio
By default, all types of WiFi clients can access a WiFi network on the access point, that is, the WiFi modes
on the access point support 802.11n, 802.11g, 802.11b, 802.11ac, 802.11na, and 802.11a clients.You can
change the modes to limit access to certain types of clients.
To change the WiFi mode for a radio:
1. Open a web browser from a computer that is connected to the same network as the access point or to
the access point directly through an Ethernet cable or WiFi connection.
2. Enter the IP address that is assigned to the access point.
A login window opens.
3. Enter the access point user name and password.
The default user name is admin. The password is the one that you specified the first time that you
logged in.The user name and password are case-sensitive.
The Dashboard page displays.
4. Select Management > Configuration > Wireless > Basic > Wireless Settings.
The Wireless Settings page displays.
5. Select the WiFi mode for the radio:
• 2.4 GHz radio. Select one of the following WiFi modes for the 2.4 GHz radio:
- 11b. 802.11n, 802.11g, and 802.11b WiFi clients can connect to the access point. However,
the speed of 802.11n and 802.11g clients is limited.
- 11bg. 802.11n, 802.11g, and 802.11b WiFi clients can connect to the access point. However,
the speed of 802.11n clients is limited.
- 11ng. 802.11n, 802.11g, and 802.11b WiFi clients can connect to the access point. This is the
default setting.
• 5 GHz radio. Select one of the following WiFi modes for the 5 GHz radio:
Manage the Basic WiFi and Radio Features
51
Insight Managed Smart Cloud Wireless Access Point WAC505 User Manual

NETGEAR WAC505 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Output current	2.5 A
Output voltage	12 V
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Internal	No
Placement	Ceiling, Wall
Product color	White
Security algorithms	802.1x RADIUS, EAP, EAP-TLS, PEAP, TTLS, WPA, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) features	SSID broadcast on/off
Antenna gain level (max)	4 dBi

Weight and Dimensions

Depth	165 mm
Width	175 mm
Height	35 mm
Weight	256 g
