NETGEAR WAC505 User Manual

6. To change the VLAN ID for the management VLAN, enter another VLAN ID in the Management VLAN
field.
By default, the management VLAN is VLAN 1. If you change the VLAN ID, be sure that the VLAN ID is
supported on your network.
7. Click the Apply button.
Your settings are saved. The access point restarts with the new VLAN settings.
Enable or Disable Spanning Tree Protocol
For locations where multiple access points are active, Spanning Tree Protocol (STP) can provide network
traffic optimization by preventing path redundancy. If your location includes more than one access point,
we recommend that you enable STP.
To enable or disable Spanning Tree Protocol:
1. Open a web browser from a computer that is connected to the same network as the access point or to
the access point directly through an Ethernet cable or WiFi connection.
2. Enter the IP address that is assigned to the access point.
A login window opens.
3. Enter the access point user name and password.
The default user name is admin. The password is the one that you specified the first time that you
logged in.The user name and password are case-sensitive.
The Dashboard page displays.
4. Select Management > Configuration > System > Advanced > General.
The General page displays.
5. Select one of the following radio buttons:
• Enable. STP is enabled.
• Disable. STP is disabled.This is the default setting.
6. Click the Apply button.
Your settings are saved.
Enable or Disable Network Integrity Check
The network integrity check function enables the access point to validate whether the upstream link is active
before the access point allows WiFi associations. Make sure that the default gateway is configured correctly.
By default, the network integrity check function is disabled.
Manage the Local Area Network and IP Settings
87
Insight Managed Smart Cloud Wireless Access Point WAC505 User Manual

NETGEAR WAC505 Specifications

General

2.4 GHz	Yes
Networking standards	IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Output current	2.5 A
Output voltage	12 V
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Internal	No
Placement	Ceiling, Wall
Product color	White
Security algorithms	802.1x RADIUS, EAP, EAP-TLS, PEAP, TTLS, WPA, WPA-PSK, WPA2, WPA2-PSK
Service Set Identifier (SSID) features	SSID broadcast on/off
Antenna gain level (max)	4 dBi

Weight and Dimensions

Depth	165 mm
Width	175 mm
Height	35 mm
Weight	256 g
