MARTNA™ 10G NETWORK ACCESS (SMARTNA-X)

COMMAND LINE INTERFACE REFERENCE |

DRAFT

• Set port 4D to half-duplex:

CONTROLLER>select slot 4

SLOT4>set port D duplex half

SLOT4>show port D

speed : set auto

duplex : set half

mdi : set auto

mastering : set preferslave

tap : off

autolock : off

lock : off

usage : undefined

port type : Registered Jack 45 (RJ45)

PORT DOWN

traffic threshold low : 0
