SPECIFICATIONS | 1 GBIT/S TAP MODULE (RJ45 & RJ45)

DRAFT

1 Gbit/s TAP module (RJ45 & RJ45)

Standards and protocols Depends upon SFP / SFP+ modules fitted

Power 11W

MTU (Maximum

Transmission Unit)

10240 bytes (untagged and tagged traffic)

Part number 5511

Ports 4 copper 10/100/1000M Ports A,B,C & D

Standards and protocols IEEE 8023 10Base-T

IEEE 8023u 100Base-TX

IEEE 8023ab 1000Base-T

Power 6W max

MTU (Maximum

Transmission Unit)

10240 bytes (untagged traffic)

10244 bytes (tagged traffic)
