EDH0162En1040 – 06/99 8.12
MM4005 Appendix C — Connector Pinouts
17 — I Analog Input 4.
18 — DGND
19 — O
Analog Output 1.
20 — O Analog Output 2.
21 — O Analog Output 3.
22 — O Analog Output 4.
23 — DGND
24 — O
Output frequency, defined by the FT command.
25 — DGND
NOTE
Remember that an I/O output bit “set” means that the transistor is con-
ducting, thus appearing to be “low”.
