Newport MM4005 User Manual

8.13 EDH0162En1040 – 06/99
MM4005 Appendix C — Connector Pinouts
C.5 GPIO Connector (37-Pin D-Sub)
This connector is dedicated to the digital I/O ports.
All outputs are open-collector type and are rated for maximum 30V and
40mA (Fig. C.2). To drive a logic input, they require a pull-up resistor.
All inputs are optocoupled and are configured as a LED in series with a
1kΩ resistor connected to the +12 V line (Fig. C.2).
Pin # Description
1 — N.C./+12 V
(1)
2 — +12 V, 25 mA
3 — +5 V,100 mA
4 — I Digital port Input 1.
5 — I Digital port Input 2.
6 — I Digital port Input 3.
7 — I Digital port Input 4.
8 — I Digital port Input 5.
9 — I Digital port Input 6.
10 — I Digital port Input 7.
11 — I Digital port Input 8.
12 — O Digital port Output.1.
13 — O Digital port Output.2.
14 — O Digital port Output.3.
15 — O Digital port Output.4.
16 — O Digital port Output.5.
17 — O Digital port Output.6.
18 — O Digital port Output.7.
19 — O Digital port Output.8.
20 — DGND
(2)
21 — DGND
(2)
22 — DGND
(2)
23 — DGND
(2)
24 — DGND
(2)
25 — DGND
(2)
26 — DGND
(2)
27 — DGND
(2)
28 — DGND
(2)
29 — DGND
(2)
30 — DGND
31 — DGND
32 — DGND
33 — DGND
34
— DGND
35 — DGND
36 — DGND
37 — DGND
1)
If optocoupling feature is activated, pin 1 outputs +12Vdc. Needs factory
service to change.
2)
If optocoupling feature is activated, pin is for external ground. Needs
factory service to change.
