MM4005 Local Mode
ber of times to repeat program execution. Enter the desired number on the
keypad and press .
The next menu confirms your choice to execute the selected program the
specified number of times or allows you to exit without execution by press-
ing the key.
To start the program sequence press the key. The display informs
you on line number 5 that a program is executing and no function keys are
available.
NOTE
The only way to stop a program or a sequence of programs from the
front panel is to turn the motor power off. Use this method for an emer-
gency stop.
When the program sequence is finished, the controller returns to the top
level menu.
→→→→→→
→
EX — Execute a program.
2.3.7 Axis Infinite Movement
The infinite movement is realized with the menu to move one or
some axis eternally (none stop).
Press the key on menu. Press the key to
activate the second Move menu. Press the key and then use the
numeric keypad to start motion. Press to exit the menu.
NOTE
Processing of an axis infinite movement is possible only if a periodicity
has been defined, and only for rotary stages.
Now, if one key of numeric keypad is pressed, one infinite displacement will
be activated or stopped:
• Key : Infinite displacement of axis 1 in negative direction.
• Key : Stop the infinite displacement of axis 1.
• Key : Infinite displacement of axis 1 in positive direction.
• Key : Infinite displacement of axis 2 in negative direction.
• Key : Stop the infinite displacement of axis 2.
• Key : Infinite displacement of axis 2 in positive direction.
• Key : Infinite displacement of axis 3 in negative direction.
• Key : Stop the infinite displacement of axis 3.
• Key : Infinite displacement of axis 3 in positive direction.
• Key : Infinite displacement of axis 4 in negative direction.
• Key : Stop the infinite displacement of axis 4.
• Key : Infinite displacement of axis 4 in positive direction.
.
