2.37 EDH0162En1040 – 06/99
MM4005 Local Mode
→→→→→
→
2.3.8 Stop Axis Infinite Movement
The infinite movement can be stopped at any time, thanks to the
menu.
Press the key on menu. Press the key to
activate the second Move menu. Press the key and then use the
numeric keypad to start motion. Press to exit the
menu.
Now, if one key of numeric keypad is pressed, one infinite displacement will
be activated or stopped:
• Key : Stop the infinite displacement of axis 1.
• Key : Stop the infinite displacement of axis 2.
• Key : Stop the infinite displacement of axis 3.
• Key : Stop the infinite displacement of axis 4.
• Key : Stop all infinite displacement and quit the menu.
→→→→→
→
Programming in Local Mode
The MM4005 controller allows the user to create and edit programs from
the front panel. This makes it a true stand-alone unit, capable of executing
most motion and motion-related functions without the help of an external
computer.
NOTE
Though very versatile, the front panel programming capabilities of the
MM4005 controller are intended to be used only for smaller, simple
motion programs. For larger, more sophisticated programs, the use of a
computer with a powerful editing environment is still recommended.
The Program mode can be invoked from both top-level or
menus. The only difference is that, when starting from the
top level menu, an additional program execution function
key is available. Both functions that are of interest for this section, program
creation and program editing, are the same regardless how they have been
activated.
MOTOR ON
MOTOR ON
Motor OFF
2.4
QUITQUIT
