2.29 EDH0162En1040 – 06/99
MM4005 Local Mode
2.2.2.26 Display Resolution
This menu modified axis position (digit number after decimal point). The con-
troller used this parameter to adjust exactly the mechanical displacement.
To change the Display Resolution, press the key. Use the numeric
keypad to enter a new value and then press to confirm the setting
and return to the previous menu.
→→→→→→
→→→
NP — Set display resolution.
Operating in Local Mode
In addition to the SETUP mode, the other two types of operations that can
be performed from the front panel of the MM4005 controller are motion-
related commands and creating or editing motion programs.
The most common use of the Local Mode is to initiate motion and motion-
related commands from the front panel. The following paragraphs describe
this in detail.
From the top level menu (the power-on default menu)
press the MOTOR button. The display will change to one similar to
Fig. 2.7. We will call this the top level motor-on menu.
Fig. 2.7 — Top level MOTOR menu.
NOTE
It is possible to press the MOTOR button while in any menu. To
avoid confusion and unexpected controller behaviors, it is strongly rec-
ommended to turn the motor power on only when in the top level
menu.
NOTE
It is possible to press the MOTOR button at any time. To avoid con-
fusion, use this capability only for emergencies. During normal opera-
tion, turn the motor power off only when in the top level
menu.
Motor ON
OFF
Motor OFF
ON
ON
0.00 mm
0.00 mm0
.000 Deg
