MM4005 Appendix C — Connector Pinouts
Fig. C.6 — 9-pin to 25-pin RS-232C interface cable.
To build a three conductor cable with a 25-pin RS-232C connector, use the
wiring diagram in Fig. C.7.
Fig. C.7 — 3-conductor, 9-pin to 25-pin RS-232C interface cable.
C.8 IEEE488 Interface Connector (24-Pin)
The IEEE488 connector has a standard configuration, shown in Fig. C.8.
Fig. C.8 — IEEE488 connector definition.
13
14
15
16
17
18
19
20
21
22
23
24
DIO5
DIO6
DIO7
DIO8
REN
GND
GND
GND
GND
GND
GND
SIG. GND
Pin #
DIO1
DIO2
DIO3
DIO4
EOI
DAV
NRFD
NDAC
IFC
SRQ
ATN
SHIELD
1
2
3
4
5
6
7
8
9
10
11
12
8
3
2
20
7
6
4
5
25-Pin D-Sub
Femal Connector
on Computer Side
1
2
3
4
5
6
7
8
9
9-Pin D-Sub
Femal Connector
on Controller Side
8
3
2
20
7
6
4
5
25-Pin D-Sub
Femal Connector
on Computer Side
1
2
3
4
5
6
7
8
9
9-Pin D-Sub
Femal Connector
on Controller Side
