EDH0162En1040 – 06/99 2.8
MM4005 Local Mode
Pressing the key enters a lower level menu that allows modifica-
tion of the currently displayed parameter. If the value needed is provided
from a short list, the new menu looks like this:
The key scrolls through the list, exits this level without
recording any modification and also returns to the previous screen
(level) but the displayed value is stored as the new entry for the selected
parameter.
If a parameter requires a numerical value, the menu level that allows modi-
fications will have the following choices:
The numerical value displayed will have a
 sign in front, indicating that a
numerical entry from the keypad is expected. For simple editing, pressing
the key erases the last digit of the numerical entry. The
key accepts the value for the selected parameter and returns to the previ-
ous menu. The key returns to the previous menu without keeping
any modifications.
NOTE
This manual contains detailed descriptions, mostly with the first time
reader in mind. To help the more experienced user looking for a quick
memory refresher, each operation description is also accompanied by a
quick front panel key sequence and, if appropriate, the remote command
that accomplishes the same function.
2.2.1.1 Language Selection
The first parameter displayed from the General Setup list is the display lan-
guage. This sets the language the controller uses to communicate with the
operator, especially through the front panel.
The MM4005 can use two languages at this time: English and French. To
change the language, from the display shown in Fig. 2.5 press the
key. The new menu displayed is
Press the key until the desired language is displayed. Press the
key to accept the selection and return to the previous menu. The
display will now use the new selected language.
→→→→→→
QUITQUITVALID
CHANGE
MODIFYGEN.SETUP
