Newport MM4005 User Manual

2.31 EDH0162En1040 – 06/99
MM4005 Local Mode
Line number 5 indicates that the keypad can be used to initiate a manual
jog. As described in paragraph 2.1.3 First Jog, each keypad row controls
one axis. The keys on the left initiate a jog in the negative direction and the
keys on the right in the positive direction. To jog at a high speed, simulta-
neously press the corresponding middle key with one of the jog direction
keys.
NOTE
The high speed manual jog velocity is set in the Axis Setup mode or by
using the MH command. The low speed manual jog velocity is 10% of the
high speed value.
→→→
MC — Set manual mode.
To exit the Manual Jog mode press the key.
There are two more function keys defined in the manual jog menu. The
key is described in the next paragraph. The key is
described in the Introduction section, Display Configuration - Status
Display paragraph.
The key displays a number of status indicators in front of each axis
identifier and a general axis condition message at the end of each axis line
(Fig. 2.9).
Fig. 2.9 — Status display.
The four status indicators are 0, –, M and + have the following meaning:
O Will appear only if a “home search” routine has been performed suc-
cessfully on that axis. It indicates that a mechanical “origin” has been
found.
– Indicates that the negative direction (left) limit switch has been activat-
ed (tripped).
M Appears when the mechanical origin switch is in “high” state. As a stage
moves from one end to the other, you will see this indicator appear and
disappear. This means that the stage has moved from one side of the
switch to the other. The state of this indicator does not affect the nor-
mal operation of the motion device. For a complete description of the
home search algorithm see Section 4, Motion Control Tutorial.
+ Indicates that the positive direction (right) limit switch has been acti-
vated (tripped).
SSTA UQIT
1:
2:
3:
4:
21
2.34 mm
nUcon
56
3-.35 mm6
nect
TU
ZERO
esUpafdokNUAMLjoey r A g
.345 Dg.
ed
+
–M+
MO
O
STATUS
STATUSZERO
QUIT
QUIT
1
4
7
2
5
8
3
6
9
.
-
0
Axis 1
Axis 2
Axis 3
Axis 4
JOG
MANUALMOTOR ON
1
4
7
2
5
8
3
6
9
.
-
0
Axis 1
Axis 2
Axis 3
Axis 4
JOG
MANU PROG .
1:
2:
3:
4:
21
2.34 mm
nUcon
56
3-.35 mm6
nect
LA
HOME
Steactionlec
MOV E
.345 Deg
ed
