Newport MM4005 User Manual

EDH0162En1040 – 06/99 2.44
MM4005 Local Mode
There are more than three possible options in the Program Editing mode,
thus the need again to split the functions in a number of screens:
This menu level is the Program Editing menu.
The key advances to the next line of the menu. When at the last
menu line, pressing it will display again the first line of the menu.
The six editing-specific commands have the following meanings:
Scroll the program listing up.
When the key is pressed, the program listing is scrolled up by one display
line.
Scroll the program listing down.
When the key is pressed, the program listing is scrolled down by one dis-
play line.
Display first line of the program listing.
When the key is pressed, the program listing on the display will start with
the first line of the program and the display changes to the first Program
Editing menu line:
Display the last line of the program listing.
When the key is pressed, the display shows the first blank line after the last
program line and then the display changes to the top of the Program
Editing menu:
To see the last program line you must press the key.
Insert a new program line.
Pressing this function key allows you to add a command line to an existing
program. The new line is inserted before the first line currently displayed.
When the key is selected, the controller activates the Line Entry
menu. Following the descriptions in the Command Line Creation para-
graph, create a new command line and, when done, press the key to termi-
nate it and return to the Program Editing menu.
Delete a program line.
Program lines cannot be edited. They can only be erased and new ones cre-
ated.
To delete a program line, use the , , , and
keys to scroll through the listing until the line to be deleted is the first one
on the display. Pressing the key will erase the line and the display
returns to the Program Editing menu.
When all the modifications have been made, press the key. The
controller will ask if you want to save the changes. Press the key to
accept the modifications and return to the Program menu.
YES
QUIT
DELETE
LASTFIRSTDOWNUP
DELETE
INSERT
INSERT
DOWN
NEXTDOWNUP
LAST
NEXTDOWNUP
FIRST
DOWN
UP
NEXT
NEXTQUITDELETEINSERT
NEXTLASTFIRST
NEXTDOWNUP
