NewSonic SonoDur2 Issue 04 09/2016 Page 14
3 Measurement Components
The SonoDur2 consists of a display unit and the herewith connected hardness measuring probe. The
hardness measuring probe can be either motorized or hand-held, equipped with the relevant
features to perform the required measurements. All probes will be attached to the display unit by
USB interface with the cable that is firmly connected to the device. In contrast to other commonly
used devices, the probe is equipped with a microcontroller that already performs the control system
functions, raw data acquisition and signal processing inside the probe.
Hence, the probe can be easily integrated into almost any measurement system via a standard USB
interface.
An overview of the scope of delivery and accessories can be found in the “Appendix” under “Section
Scope of Delivery and Accessories“, page 61.
3.1 Device Connections
Figure 3.1
