SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
Parameter Description
Distortion
This value is added to the Min margin and Tgt margin value.
(Refer to Figure 78)
This is different per ModCod.
ACM Monitoring only
Set this parameter to Disabled to activate FlexACM.
When ACM monitoring only is set to enabled,
then the ACM messaging is copied to a log file
and not carried out..
This is used to represent the impact of
FlexACM without changing the ModCod
parameters.
ACM fw sig plane
Select the control plane for the ACM controller forward
signalling:
• MonCon management IP network
• Inband RF channel
9.1.1.6 ACM Client
The ACM client is used to communicate with the controller. Define the following
parameters to configure the client.
EL470 >> Modem >> Control >> Demodulation >> ACM client
The following parameters can be defined.
Parameter Description
Virtual ACM client id
This parameter identifies an ACM demodulator within the
ACM controller.
Redundant demodulators for which ACM is enabled must be
configured with the same Virtual ACM client id.
When the embedded ACM controller is used on the
modulator, this parameter is the MonCon IP address of the
active demodulator.
When the EL860 ACM controller is used, this parameter is
the AIRMAC address on which the demodulator listens.
When inband RF is used this parameter is set to “-“. This
disables the Virtual ACM client id. In this state the MAC
address of the interface port is used as id.
ACM rt sig plane
Select the controle plane for the ACM controller return
signalling:
• MonCon management IP network;
• Inband RF channel.
