7 BLOCK DIAGRAM
The following block diagrams refer to the default configuration with
L-band options.
7.1 Monitoring and Control
This block is used for monitoring and control of the device.
This block is generic for all devices.
The following actions are available:
• Alarm Output;
• Remote Monitoring and Control over LAN or RS232/RS485;
• Front Panel.
For more information refer to section 4.2.1.
7.2 EL 170 Modulator
In this diagram the modulator is split up into the following functionalities.
• Monitor and Control;
• Modulator Functionality.
Figure 55 - EL170 Modulator
