6.7.1.2 Importing a Configuration
The possibility exists to import all 48 device configurations at once as a “.cfg” file
from a local computer.
Proceed as follows to import a configuration set:
Click the Configs Tab;
Click the Import button;
Browse to the location of the stored “.cfg” file;
Select the “.cfg” file and click Open. The stored configurations are loaded into
the Newtec device;
It is possible to load any of the 48 configurations to view or test
them.
The user has two options:
• The user can keep the imported configurations. In this case, the user must
save the current imported configuration in bootconfiguration;
The user can decide to delete the imported configurations. In this case the user
must restart the device. The device will start up using the same ootconfiguration as
the previous start up..
