SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
3.2 Power Supply
This equipment is provided with a protective earthing incorporated in the power
cord. Be careful to insert the mains plug only in a socket outlet provided with a
protective earth contact (TN type power supply). Any interruption of the protective
conductor inside or outside the equipment is likely to make the equipment
dangerous. Intentional interruption is prohibited.
Install and connect the equipment to the mains power supply system in compliance
with local or national wiring installation standards. Position the equipment so that
the mains supply socket outlet for the equipment is near the equipment and can be
easily accessed or that there are other suitable means to disconnect from the
mains supply.
3.2.1 Main Power Supply
This power supply is set to operate from 100 to 240Vac to 47-63Hz.
3.2.2 DC BUC Power (optional)
This power supply is set to operate from
The output is provided on the N connector.
Remove the power on the equipment before any action is taken
on this connector.
The maximum current provided on this connector is 4A.
3.3 Cable Distribution System
Install the equipment in accordance with the applicable provisions of NEC Article
810 for US and with CEC section 54 for Canada.
Before connecting the coax to the equipment, make sure that the equipment is
properly earthed. The screen of the used coax cable should be grounded
according to the local regulations.
3.3.1 Technical Earthing
On the rear panel of the equipment a technical earthing is available (an unmarked
terminal on the right side of the equipment).
It is provided to:
