Newtec EL170 - Options

Options
User Manual for EL170/970/470 IP Satellite Modulator/
Demodulator/Modem
version 4.2
xiii
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
OPTIONS
EL170 IP satellite modulator
Default Configuration
Ordering n°
DVB-S/DVB-DSNG-DVB-S2 IP modulator with GbE interface, data piping, MPE, ULE, GSE and XPE
encapsulator, CCM, Multi-stream, SNMP
EL 170
Modulation & Baud rate: QPSK-8PSKP, 5Mbaud
Output interface: L-band (950 -1750 MHz)
Configuration
Options
Category
Max. 1 option per category
Output Interface
L-band (950-1750 MHz)
Default
IF (50-180 MHz)
AA-02
L-band + 10MHz for BUC
AA-03
L-band + 10MHz + 24Vdc for BUC
AA-12
L-band + 10MHz + 48Vdc for BUC AA-13
Extended L-band ( 950-2150 MHz)
AA-18
IF+ L-band
AA-06
Modulation & Baud
rate
QPSK-8PSK 5Mbaud
Default
QPSK-8PSK 15Mbaud *
AB-06
QPSK-8PSK 33Mbaud *
AB-07
QPSK-8PSK 45Mbaud *
AB-08
QPSK- 8PSK-16APSK 5Mbaud *
AB-09
QPSK- 8PSK-16APSK 15Mbaud *
AB-10
QPSK- 8PSK-16APSK 33Mbaud *
AB-11
Q/8PSK-16APSK-32 APSK 5Mbaud *
AB-13
Q/8PSK-16APSK-32 APSK 15Mbaud *
AB-14
Q/8PSK -16APSK -32APSK 33Mbaud *
AB-15
All Modcods, BBFinput (for use with EL860)*
AR-01
Additional Options
Category Max. 1 option per category
10MHz reference
In/Out
Internal reference : 1ppm GR-01
Internal reference : 0,01 ppm
GR-02
Encryption
AES 64 bit encryption
AG-01
Predistortion
Equalink *
AC-01
VCM-ACM
Embedded VCM (no shaping)*
AN-01
(*) upgradeable via
license key
Services
Category
Max. 1 option per category
Assistance
Care Pack Basic
GA-06
Care Pack Extended
GA-07
