Graphical User Interface (GUI)
User Manual for EL170/970/470 IP Satellite Modulator/
Demodulator/Modem
version 4.2
84
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
6.4.2 Parameters
6.4.2.1 Parameter Dialog Box Types
The GUI contains different types of parameter dialog boxes to set up all
parameters during a configuration.
Dialog box
type
Example
Drop-down
list box
Data field
Checkbox
Table
Functional
group
Table 9 – Parameter Interface Type Examples
In a table type dialog box, columns can be moved to a different
position in the table.
