6.4 Configuring the Device Using the GUI
6.4.1 Introduction
Configuration of the device is done by changing parameters. Accessing and editing
the device parameters can be done via multiple paths in the GUI.
• Common used parameters are set using the functional blocks on the overview
tab.
• Non-commonly used parameters can be set on the parameter pages of the tree
structure. Experienced users of the device can set all parameters using the tree
structure parameter pages.
• A configuration wizard is built into the GUI. This wizard is very useful for non-
experienced users. It guides the user step by step through the configuration and
gives extra information. The wizard can be accessed through the Wizard button
on the Miscellaneous tab of the function controls.
It is strongly advised to use the wizard to configure the device
parameters the first time the device is operated after physical
installation.
