Physical Description
User Manual for EL170/970/470 IP Satellite Modulator/
Demodulator/Modem
version 4.2
41
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
4 PHYSICAL DESCRIPTION
4.1 Front Panel Description
Figure 9 – EL170 IP Satellite Modulator Front Panel
Figure 10 – EL970 IP Satellite Demodulator Front Panel
