9.5.4 VLAN Forwarding
The VLAN forwarding setting is used to configure how the VLANs are mapped to
the satellite payload.
Figure 94 – VLAN Forwarding
The following steps are done in the modem:
1. Inspect: the Ethernet type;
2. Filter: the VLAN Identifier;
3. Strip or don’t strip . (Add-drop or Keep) the VLAN
Go to the following menu to configure the device settings:
EL470 > Control > Interfaces > ipencap
