SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
APPENDIX A – USER DEFINED MENU
You can configure the user menu according to your needs. In this way, you can
create a quick access to those control, monitor and testing parameters that you
need to change or monitor regularly. In addition, you can also change the order in
which the menu items are presented to meet your specific demands. This is very
useful in, for example, the DSNG applications. Here you can pre-configure the
general parameters and store them in the default boot-configuration. You can then
make all relevant parameters that need a quick change during link setup available
as a group in the user menu. When you have done this, you can operate the IP
Satellite Modulator without having to go through all the different menus. A typical
example would be to group the parameters output frequency, output level and
transmit while leaving all other parameters untouched.
The following is an example for the EL170 modulator. The same
procedure can be used for the other devices.
Defined user menu
Choose EL170 >unit>setup> User menu and click OK
EL170/Unit/setup
User menu: <press OK, ESC when done>
Choose EL170 > Unit > Setup > User menu and click OK. This brings up the first
item from the EL170 > Control menu:
EL170/Control not present
<example parameter> <OK> to add
Click OK to add this menu to the list of menu items that is visible in the user menu
or press the 'right arrow' key to move to the next menu item in the control, monitor
and test menu. The available list contains all the menu items when the device is
in "expert mode".
Click OK to change the display to:
EL170/Control present
<example parameter> <OK> to remove
The above indicates that this menu item is present in the user menu. To remove it,
click OK again.
After a "reset to factory defaults" the user menu contents are lost.
