Appendix C Technical
Specifications
User Manual for EL170/970/470 IP Satellite Modulator/
Demodulator/Modem
version 4.2
185
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
EL970 IP Satellite Demodulator
Input interface
Dual L-band input (default)
Connector 2 x F-type (F), 75 ohms;
Return loss > 7 dB;
Level -65/-25dBm;
Frequency 950 - 2150 MHz;
Adjacent signal < (Co+7) dBm/Hz where Co = signal level density.
IF-band input (optional, replaces one L-band input)
Connector BNC (F) - 75 ohms;
Return loss > 15 dB;
Level -55 to -15 dBm;
Frequency 50 - 180 MHz;
Adjacent signal < (Co+7) dBm/Hz where Co = signal level density.
LNB power and control
max. current 350 mA (on selected IFL input);
voltage
- 11,5 -14 V (Vertical polarization);
- 16 -19 V (Horizontal polarization) & additional 22kHz +/- 4KHz (band
selection according to universal LNB for Astra satellites & DiSEqC
command transmission);
10 MHz reference.
Demodulation
Supported modulation schemes and FEC
DVB-S/DSNG:
Outer/Inner FEC: Reed Solomon /Viterbi
ModCods:
- QPSK: 1/2, 2/3, 3/4, 5/6, 7/8
- 8PSK: 2/3, 5/6, 8/9
- 16QAM: 3/4, 7/8
DVB-S2:
Outer/Inner FEC: BCH/ LDPC
ModCods:
- QPSK: 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
- 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
- 16APSK: 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
- 32APSK: 3/4, 4/5, 5/6, 8/9, 9/10
