Options
User Manual for EL170/970/470 IP Satellite Modulator/
Demodulator/Modem
version 4.2
xiv
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
Option AA-06 IF+Lband: Switching the IF frequency from 70 to 140MHz or 140MHz
to 70MHz has no impact on the L-band frequency.
EL970 IP satellite demodulator
Default Configuration
Ordering n°
DVB-S/DVB-DSNG-DVB-S2 IP demodulator with GbE interface, data piping, MPE, GSE, XPE and ULE
decapsulator,Multistream, VCM, SNMP
EL970
Input interface: L-band ( 950 - 2150 MHz)
Modulation & Baud rate: QPSK-8PSK 30Mbaud
Configuration Options
Category
Max. 1 option per category
Input Interface
L-band
Default
L-band + 10MHz
AJ-02
IF+ L-band
AJ-03
IF + L-band + 10MHz
AJ-04
Modulation & Baud rate
QPSK-8PSK 33Mbaud
Default
QPSK-8PSK 45Mbaud *
AL-08
QPSK- 8PSK-16APSK 33Mbaud * AL-11
Q/8PSK 16APSK -32APSK 33Mbaud *
AL-15
Additional Options
Category
Max. 1 option per category
10MHz reference In/Out
Internal reference : 1ppm
GR-01
Internal reference : 0,01 ppm
GR-02
Decryption AES 64 bit decryption AA-01
ACM
ACM client
AR-04
(*) upgradeable via
license key
Services
Category
Max. 1 option per category
Assistance
Care Pack Basic
GA-06
Care Pack Extended
GA-07
