EL470 IP satellite modem
Default Configuration
Ordering n°
DVB-S/DVB-DSNG-DVB-S2 IP modem with GbE interface, data piping, MPE, ULE, GSE and XPE
encapsulator, Multistream CCM, L-band (950 - 2150 MHz) demod input, SNMP
EL 470
Output interface Modulator: L-band (950 - 1750 MHz)
Modulation & Baud rate modulator: QPSK-8PSK 2Mbaud
Modulation & Baud rate demodulator: QPSK-8PSK 5Mbaud
Configuration Options
Category
Max. 1 option per category
Modulator
L band (950-1750 MHz)
Default
Output Interface IF (50-180 MHz) AA-02
L-band + 10MHz for BUC
AA-03
L-band + 10MHz + 24Vdc for BUC
AA-12
L-band + 10MHz + 48Vdc for BUC
AA-13
Extended L-band ( 950-2150 MHz) AA-18
Demodulator
dual L-Band
Default
input interface
IF + L-band (only with IF Mod output)
AJ-03
Modulation & Baud rate QPSK-8PSK 2Mbaud Default
QPSK-8PSK 5Mbaud*
AB-05
QPSK-8PSK 15Mbaud *
AB-06
QPSK-8PSK 33Mbaud *
AB-07
QPSK-8PSK 45Mbaud *
AB-08
QPSK- 8PSK-16APSK 2Mbaud *
AB16
QPSK- 8PSK-16APSK 5Mbaud *
AB-09
QPSK- 8PSK-16APSK 15Mbaud *
AB-10
QPSK- 8PSK-16APSK 33Mbaud *
AB-11
Q/8PSK-16APSK PtP FlexACM control 2Mbaud *
AB-22
Q/8PSK-16APSK PtP FlexACM control 5Mbaud *
AB-23
Q/8PSK-16APSK PtP FlexACM control 15Mbaud *
AB-24
Q/8PSK-16APSK PtP FlexACM control 33Mbaud *
AB-25
Q/8PSK-16/32APSK PtP FlexACM control 2Mbaud * AB-12
Q/8PSK-16/32APSK PtP FlexACM control 5Mbaud *
AB-19
Q/8PSK-16/32APSK PtP FlexACM control 15Mbaud *
AB-20
Q/8PSK-16/32APSK PtP FlexACM control 33Mbaud *
AB-21
All Modcods, BBFinterface (for use with EL860)* AR-01
