For every functional block of the device you can see the following information:
• Arrows from and towards the functional block;
• Relevant parameters to change and colour of the functional block itself;
• A link at the right top corner. When you click this link you have a detailed;
overview page of that specific functional block.
The colour (red, yellow, green or grey) of each block or arrow in the diagram is
determined by its condition.
The following conditions can occur:
• Error: The block and/or arrow has a red colour. The state is not OK. There is an
alarm; a counter indicates an error(s) or a counter does not change as
expected.
• Warn: The block and/or arrow has a yellow colour. The state is not as expected.
There is an alarm or a counter does not change as expected.
• OK & IN-USE: The block and/or arrow has a green colour.
• IDLE: The block and/or arrow has a grey colour.
Click the detailed view icon (
) in the block heading to open the detailed overview
page of that functional block. A new tab containing the function details opens in the
central stage area.
When a value changes in the central stage area it briefly gets a
yellow background.
