TECHNICAL CHARACTERISTICS OF THE PRODUCT
WARNINGS: • All technical specifications stated in this section refer to an ambient temperature of 20°C (± 5°C). • Nice S.p.A. reserves the right to apply modifi-
cations to products at any time when deemed necessary, maintaining the same intended use and functionality.
Model M3BAR M5BAR M7BAR L9BAR
Product Type Road barrier for residential use complete with electronic control unit
Useful conduit (m) 2,32 ÷ 2,82 3,17 ÷ 4,82 5 ÷ 7 7 ÷ 9
Maximum torque on start-up (Nm) 100 200 300 400
Nominal torque (Nm) 30 70 90 130
Manoeuvre time (sec adjustable) 1.5 – 3 3 – 6 6 – 10 8 – 12
Maximum operating cycle 600 350 200 150
frequency at nominal torque continuous use continuous use
(the control unit limits the work
cycles to the maximum set in table T3)
Durability See chapter 3 - paragraph 3.2.1
Power supply voltage 230V 50/60Hz 230V 50/60Hz 230V 50/60Hz 230V 50/60Hz
Power supply voltage /V1 120V 50/60Hz 120V 50/60Hz 120V 50/60Hz 120V 50/60Hz
Maximum power absorbed 150 110 110 160
on start-up (W)
Maximum power at nominal 40 50 40 50
torque (W)
Insulation class 1 1 1 1
Emergency power supply Yes (with PS224 accessory)
Photovoltaic power supply Yes (with SYKCE accessory)
FLASH output for 1 LUCYB, MLB or MLBT flashing light signal (12V – 21W)
LIGHT output for optional accessory XBA4 “pole lights”
SCA output for signal indicator 24V (max 10W)
Output for flashing light/ with optional accessories XBA7 led flashing light or XBA8 led traffic light
traffic light on cover
BLUEBUS output 1 output with maximum load of 12 Bluebus units
“STOP” input For normally closed, normally open, 8.2 kΩ constant resistance or OSE optical type contacts;
in self-learning mode (a change from the memorised state prompts the “STOP” command)
“STEP-STEP” input For Normally Open contacts
“OPEN” input For Normally Open contacts
“CLOSE” input For Normally Open contacts
Radio connector SM connector for receiver types SMXI, SMXIS, OXI or OXIT
Radio AERIAL input 50 Ω for RG58 or similar type cable
Loop Detector Inputs 2 per loop with a circumference from 2 to 16 m
Nominal Loop inductance 100 to 400 μH
Programmable functions 8 ON-OFF functions and 8 adjustable functions (see tables 6 and 8) and additional programming
through the Programming Unit and Oview Command
Functions in self-learning mode Self-learning of devices connected to the BlueBus output. Self-learning of “STOP” type devices (contacts NO, NC
or 8.2kΩ resistance). Learning of pole opening and closing positions and calculation of the points of deceleration
and partial opening. Self-learning of the “Version”
Operating temperature -20°C ... +55°C -20°C ... +55°C -20°C ... +55°C -20°C ... +55°C
Protection rating IP54 IP54 IP54 IP54
Dimensions (mm) 400 x 299 x 1215 h 400 x 299 x 1215 h 400 x 299 x 1215 h 500 x 299 x 1215 h
Weight 80 kg 80 kg 85 kg 98 kg
