ACCESS GATEWAY
System Administration 137
The default gateway is the IP address of the router that the Access Gateway uses to
transmit data to the Internet.
10. Multiple NAT IP addresses for Session Expansion can be individually added by entering
each desired address in the NAT IP Address field and left clicking the Add button. Up to
four additional NAT IP Addresses can be added. To remove additional addresses, enter
the address in the field and left click Remove. To enable usage of these addresses, check
the
Enable additional NAT IP addresses checkbox.
11. When finished, you must reboot the system for the new settings to take effect. Click on the
check box for Reboot after changes are saved? to reboot the system after saving your
changes.
12. Click on the Submit button to save your changes and reboot the system, or click on the
Reset button if you want to reset all the values to their previous state.
Managing the Log Options {Logging}
System logging creates log files and error messages generated at the system level. AAA
logging creates activity log files for the AAA (Authorization, Authentication, and Accounting)
functions. You can enable either of these options.
Although the AAA and billing logs can go to the same server, we recommend that
they have their own unique server ID number assigned (between 0 and 7). When
managing multiple properties, the properties are identified in the log files by their
IP addresses.
