ACCESS GATEWAY
284 System Administration
2. Enter the Internal IP Address.
3. Enter the Internal Port reference.
4. Enter a valid MAC Address.
5. Enter the External IP Address.
6. Enter the External Port reference.
7. Optional: Enter the Remote IP Address. Leave this field set to zero if you want to connect
to the internal device from any network-side workstation.
8. Optional: Enable the Protect with Source IP-based Access Control option. Enabling
this will only allow address in the source-based access control list to connect on this port
mapping. Source-based access control needs to be enabled for this to be in effect.
9. Optional: Enter the Remote Port reference. Leave this field set to zero if you want to
connect to the device from any TCP/UDP port of a network-side workstation.
10. Select the protocol (TCP or UDP) from the pull-down menu.
11. Click on the Add button to add this static port, or click on the Reset button to reset all
values to their previous state.
For more information about Static Port-Mapping, see also:
 “Displaying the Static Port Mapping Table {Static Port-Mapping}” on page 200.
 “Deleting Static Ports {Static Port-Mapping Delete}” on page 284.
Deleting Static Ports {Static Port-Mapping Delete}
Static Port-Mapping allows the network administrator to setup a port mapping scheme that
forwards packets received on a specific port to a particular static IP (typically private and mis-
configured) and port number on the subscriber side of the Access Gateway. The advantage for
the network administrator is that free private IP addresses can be used to manage devices (such
as Access Points) on the subscriber side of the Access Gateway without setting them up with
public IP addresses.
This procedure shows you how to add static ports.
Ensure that the device with the Internal IP Address has been added to the
subscriber’s table.
The External IP address field will default to the IP address of the Access
Gateway.
