ACCESS GATEWAY
Installing the Access Gateway 45
Start a HyperTerminal (or equivalent) session to communicate with the AG via the
product’s console interface. Use the following configuration settings for your session:
Subscriber-side Ethernet Connection:
Connect a cross-over Ethernet cable between the product’s Eth1 port and your computer’s
Ethernet port.
5. Setup a SSH client to establish a SSH session to communicate with the NSE gateway via
the administrative IP address after the Access Gateway finishes powering up. The
administrative IP address is 172.30.30.172.
6. Power up your computer and turn on the product. You can then configure the WAN for a
static IP address, DHCP Client or PPPoE client using appropriate configuration guidelines
that follow in order to obtain the license key. Once the key has been obtained, the web
management interface (WMI) can be used to continue configuration.
LCD Messages
Some Access Gateway hardware models are equipped with an LCD panel, that displays the
following system information:
Platform and Firmware Version Installed
Primary IP Address of the NSE
NSE ID
Active Subscribers.
Bits per Second Data Bits Parity Stop Bits Flow Control
9600 8 None 1 None
IP Address 172.30.30.173
Netmask 255.255.0.0
Gateway 172.30.30.172
DNS (If Required) 4.2.2.1
