Figure 58 illustrates the logic flow of an IP filter.
Action Matched Press [SPACE BAR] and then [ENTER] to select the
action for a matching packet.
Check Next
Rule
Forward
Drop
Action Not Matched
Press [SPACE BAR] and then [ENTER] to select the action
for a packet not matching the rule.
Check Next
Rule
Forward
Drop
After you configure Menu 21.1.1.1 - TCP/IP Filter Rule,
press [ENTER] at the message “Press ENTER to Confirm”
to save your configuration, or press [ESC] to cancel. This
data is displayed on Menu 21.1.1 - Filter Rules Summary.
Table 25 TCP/IP Filter Rule Menu fields
Field Description Options
