94 Chapter 9 Network Address Translation (NAT)
N0115791
Figure 34 Menu 15.1.255 – SUA Address Mapping Rules
Table 18 explains the fields in Figure 34.
Menu 15.1.255 - Address Mapping Rules
Set Name= SUA
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ------
1. 0.0.0.0 255.255.255.255 0.0.0.0 M-1
2. 0.0.0.0 Server
3.
4.
5.
6.
7.
8.
9.
10.
Press ENTER to Confirm or ESC to Cancel:
Note: Menu 15.1.255 is read-only.
Table 18 SUA Address Mapping Rules
Field Description Example
Set Name This is the name of the set you selected in menu
15.1 or enter the name of a new set you want to
create.
SUA
Idx This is the index or rule number. 1
Local Start IP Local Start IP is the starting local IP address (ILA). 0.0.0.0
