96 Chapter 9 Network Address Translation (NAT)
N0115791
Figure 35 Menu 15.1.1: First Set
Ordering your rules
Ordering your rules is important because the BCM50a Integrated Router applies
the rules in the order that you specify. When a rule matches the current packet, the
BCM50a Integrated Router takes the corresponding action and the remaining
rules are ignored. If there are any empty rules before your new configured rule,
Menu 15.1.1 - Address Mapping Rules
Set Name= NAT_SET
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ------
1.
2
3.
4.
5.
6.
7.
8.
9.
10.
Action= Edit Select Rule=
Press ENTER to Confirm or ESC to Cancel:
Note: The Type, Local and Global Start/End IPs are configured in
menu 15.1.1.1 (described later) and the values are displayed on the
screen shown in Figure 36.
