Introduction
1040-0011 Revision 5
Changes from previous revision
First release of this manual.
Added recommended power connection diagram
Added Coherent C70 Laser Adapter
Fixed errors in High-power Laser Adapter pin-outs
Updated Aux I/O module outline drawing to show female COM connector
Use new CT logo and fixed Japan support e-mail address
Added appendix covering the IPG YLP laser adapter
Added notes to the high-power laser adapter about mislabeled silkscreen on
the Rev C adapter boards
Deleted “Future use” references where the feature is now supported
Fixed AUX_GPI and AUX_GPO numbering to go from 1-4
Fixed reference to GP input conditioning in Aux I/O module
Fixed GPI and GPO pin names on MOTF connectors
Added additional info on IPG YLP-HP Type B interface
Adjusted J3 image to match physical view
Added scan-head power supply to wiring recommendation
Refined the definition of the AUX_READY signal which is renamed to
AUX_ERROR_READY_N
Changed 25P D-Sub M from 25P D-Sub F on the IPG laser adapter
Added signal conditioning diagrams for the extended I/O
Clarified description of AUX_RESET signal
Updated GPIO module figures regarding AUX_ERROR_READY_N signal
Updated the SPI Laser connector diagram
