Installation
1040-0011 Revision 33
Connector J13 (Auxiliary) Signal Descriptions
Odd-numbered Pins (1 – 63)
Even-numbered Pins (2 – 64)
AUX_XY2_STAT2
Port 2 XY2-100 Status 2 (reserved)
Note: Before use with a scan head
this signal must be signal
conditioned with differential
drivers and receivers.
AUX_XY2_INPOS
Port 2 XY2-100 In Position
Note: Before use with a scan head
this signal must be signal
conditioned with differential drivers
and receivers.
SPI_SS_AUX_N
Reserved for future use
SPI_CLK
Reserved for future use
SPI_MOSI
Reserved for future use
SPI_MISO
Reserved for future use
N/C
Reserved for future use
GND
Digital ground reference
VCC12V
12V source for use with analog
circuitry
CHASSIS
Expected to be tied to earth ground
4.5.5 MOTF-1 Signal Pinouts (Connector J14)
The following figure contains the pinout drawing for Connector J14 (MOTF-1).
