Installation
1040-0011 Revision 44
Connector J18 (Laser) Signal Descriptions
Odd-numbered Pins (1 49)
Even-numbered Pins (2 50)
ESTOP_LOOP
Used to access laser interlock
49
50
ESTOP2_LOOP
Used to access laser interlock
Notes On Interlock Behavior: LASER_STAT[2 0]_ISO can be configured by the software to generate
an interlock exception if an inappropriate signal level is received. See the SMC Software Reference
Manual for details on how to configure this behavior.
4.5.10 E-STOP (Connector JP6)
This connector provides access on the SMC base board to the laser connector J18 ESTOP_LOOP and
ESTOP2_LOOP signals. The ESTOP_LOOP pin on Connector JP6 goes to Pins 20 & 49 on Connector
J18. Likewise, The ESTOP2_LOOP pin on Connector JP6 goes to Pins 24 & 50 on Connector J18
This connector permits a PLC to access to the Interlock/Safety control signal for the laser when direct
cabling between the laser and the SMC (e.g. IPG-YLP) or SMC Laser Adapter (e.g. SPI) is used. VCC
and GND signal are provided on the connector to facilitate pulling the ESTOP_LOOP to an appropriate
state when the interlock is being bypassed.
The following figure contains the pinout drawing for the E-STOP connector JP6.
Note: There is no active monitoring by the SMC of the ESTOP_LOOP signal.
