Novanta ScanMaster User Manual

Installation
1040-0011 Revision 36
Connector J15 (MOTF-0) Signal Descriptions
Odd-numbered Pins (1 –9)
Even-numbered Pins (2 – 10)
AUX_BMOTF0_DP
Primary mark-on-the-fly encoder
input. Expected to be connected
to an RS-485 positive “B” phase
differential signal or a 5V TTL
signal.
3
4
AUX_BMOTF0_DN
Primary mark-on-the-fly encoder
input. Expected to be connected
to an RS-485 negative “B” phase
differential signal.
START
External trigger input
Note: This function can also be
achieved using the
AUX_START_ISO and AUX_START
signals.
5
6
GND
Digital ground reference
EXT_VCC5V0
5 Volts available for encoder power
7
8
GND
Digital ground reference
AUX_GPO1
General purpose output
9
10
CHASSIS
Expected to be tied to earth
ground
4.5.7 Control Signal Pinouts (Connector J16)
The following figure contains the pinout drawing for Connector J16 (Control Signals).
