164 Océ 3165 User Manual
4 Open the stapler by pulling the lever to the left and then lifting it.
[100] Opening the 50 sheet stapler
Note: If the key operator is the only person authorized to refill staples, you
will not be able to open the stapler because it will have been latched. In
this case you should contact the key operator.
5 Remove the empty staple cartridge by pulling it up (see figure 101).
[101] Removing the staple cartridge
6 Remove any remaining staples from the stapler anvil.
7 Place a new cassette by pushing it downward until it clicks into place, making
sure that the first strip of staples does not slide out of the staple cartridge.
8 Close the stapler and pull the lever to the left to lock it.
9 Close the top cover.
10 Slide the frame to the left until it locks into place.
11 Close the paper compartment door.
