Chapter 7 Routine Maintenance
269
ENDOSCOPE REPROCESSOR OER-Pro Operation Manual
7. Attach the printer roll axle on the printer roll axle mount of the printer.
Figure 7.115
8. Hold the two edges of the printer paper roll as shown in Figure 7.116 below
and insert the paper into the printer paper roll inlet of the printer. Insert so
that the printer paper roll is between the projections as shown in Figure
7.117.
Figure 7.116
9. The printer paper roll is fed automatically.
Figure 7.117
To Next Page
