Status indicator
Color Status
Red/
Illuminated
LOCKOUT state due to a
recoverable error
Red/
Blinking
LOCKOUT state due to a
replacement-recommended error
Orange/
Illuminated
Safety outputs are
instantaneously turned OFF due
to ambient light, vibration, or noise
Orange/
Blinking
The Intelligent Tap is in
LOCKOUT state
RestoresReplace light curtain
* Based on Omron investigation in June 2018.
16
Easy maintenance
Even inexperienced operators can easily check status and replace light curtains.
Easy error diagnosis with clear color indicators
Back up and restore settings with Intelligent Tap
The light curtain status can be checked at a glance.
Replacement and setting time during maintenance
can be reduced to 1/10 or less*.
Status indicator
Plug & Work for quick replacement
Lamp
Clear LED indicators with labels help
perform predictive maintenance by dirt
detection and determine the optimal
replacement timing.
Colors and patterns indicate the status
Install the Intelligent Tap to automatically copy the
settings of the replaced light curtain to a new one.
Virtually anyone can easily replace light curtains
and immediately restart the machine.
Output status can be
checked at a glance.
F39-SGLP
Output information
can be assigned to
the lamp and ABI.
Status, such as
light intensity drop,
can be checked
from a distance.
For information on other indicators, refer to Indicator on page 63 or Troubleshooting on page 95.
Intelligent Tap
F39-SGIT-IL3
Quick
replacement
Replacement
and setting time
reduced to
1/10 or less*
Maintenance with no special skills requiredMaintenance
